Grafting Tailscale onto the Pi

Photo of Xe Iaso

Imagine this scenario: you're setting up that Raspberry Pi you were finally able to get your hands on after years of them being literal unobtanium, you look at the device, and then at your cables in pure despair. The Raspberry Pi 4 has two HDMI ports, but they're not normal HDMI. They're micro-HDMI and you don't have adaptors. Oh, you can figure out the IP address in your DHCP table, and then you could go through and connect over SSH, get told you need to change your password, get kicked out, and then reconnect. Then you can get around to installing Tailscale or whatever.

This does work, but it is insufficiently magic for our needs. What if you could just turn your Pi on and have it magically appear on your tailnet? Keep reading, because that's exactly what we're gonna cover today: grafting Tailscale into your Raspberry Pi with the magic of the cloud.

A green-haired chibi character in the style of Animal Crossing wearing a hoodie and sitting on a log in an idyllic forest with a blue sky during summer.
Image generated by Anything v3+Tanuki, prompt: A green-haired chibi character in the style of Animal Crossing wearing a hoodie and sitting on a log in an idyllic forest with a blue sky during summer.


So let's put all this together. First you need to download a few things:

Then open Etcher and load the Ubuntu image. Select your SD card as the target and then hit the "Flash!" button. After entering your sudo password, let it cook. It may take up to 15 minutes depending on the grade of flash in your card, how your SD card reader connects to your computer, and the current phase of the moon.

Once that's done, eject the SD card and plug it back in. In Finder, you should see a volume called system-boot that has a file named user-data in it. Now download the script from GitHub and put it in your Downloads folder. Then open a terminal window and run as root:

sudo python3

It'll ask you a few questions, but be sure to give it an authkey so that your Pi can join your tailnet on boot. This is a place where having ACL tags can be useful, especially if you tag it with something like tag:exit so that you can limit access to it.

When it's done, eject your SD card and plug your Pi into ethernet and power. It will take a while to boot and converge (usually 15 minutes at most), but when it's done it will show up in your tailnet.

Now for the real magic, you can directly SSH into it without a password using Tailscale SSH. If your Pi is named mincemeat, you can run this command:

ssh ubuntu@mincemeat

No passwords or keys required! You can do whatever you like from here from setting up Tailscale Serve to point to a local Gitea install, setting up an internal wiki, or anything you can imagine. You can even expose things to the public internet with Funnel.

the avatar for Xe Iaso

If you chose to make your Pi an exit node, you will need to confirm that in the admin console. Once you've done that, you can enable the exit node in the Tailscale menulet, system tray icon, or in the app.

Windows users

If you're running this on Windows, your best bet is going to be manually editing the user-data file as specified in the how this works section of the article. Sorry!

How it works

Now that you have your Pi set up, let's take a moment to learn how this all works and why I said it's using the magic of the cloud.

When you set up an instance in AWS or a droplet in Digital Ocean, you don't usually just get dumped a username and password and told "good luck". There's ways to pre-load SSH keys and other configuration via the "user data" field. This allows you to use everyone's favorite configuration language to tell the platform how it should mangle the base image to your needs: YAML. This is powered by cloud-init, a tragically under-documented critical part of the modern internet.

Now you may be wondering something like:

A picture of the character Aoi in a wut mood.}

Okay, wait. You just said that we're going to be using Ubuntu on a Raspberry Pi in order to do this. How is the cloud relevant?

It's relevant beacuse the Ubuntu Raspberry Pi images ships with cloud-init! This lets you steal the YAML fire from the cloud gods so that you can assimilate your pi into your tailnet. Not to mention, it's actually possible to buy Raspberry Pi boards without having to sign over your kidneys or hunting them out from scalpers like we did with PS5s.

And when Prometheus stole the YAML from the gods, they cried out "NO!". But Prometheus did not understand, for all he heard was "false".

cloud-init installs Tailscale

One of the things cloud-init offers is the runcmd block. This allows you to make a list of arbitrary shell commands that are run as root some time after boot. Here's an example runcmd block that the shell script makes:

- ['sh', '-c', 'curl -fsSL | sh']
- [
"echo 'net.ipv4.ip_forward = 1' | sudo tee -a /etc/sysctl.d/99-tailscale.conf && echo 'net.ipv6.conf.all.forwarding = 1' | sudo tee -a /etc/sysctl.d/99-tailscale.conf && sudo sysctl -p /etc/sysctl.d/99-tailscale.conf",
- ['tailscale', 'up', '--ssh', '--advertise-exit-node', '--authkey=changeme', '--hostname=ubuntu']
- ['sh', '-c', 'sudo hostnamectl hostname ubuntu']

the avatar for Xe Iaso

If you're using Windows, this is the key thing to copy into the user-data file.

This automatically installs Tailscale, enables the sysctl settings for IP forwarding on Linux, authenticates you to Tailscale, and sets the hostname using hostnamectl. When your Pi boots, it will run all of these commands and this should result in Tailscale activating on boot.

the avatar for Xe Iaso

You can use the same basic user data commands for spinning up new Digital Ocean droplets or Google Cloud instances. cloud-init has a lot of other functionality including:

  • Pulling an Ansible playbook and running it on boot
  • Installing arbitrary packages
  • Creating user accounts for other people in your tailnet
  • Importing SSH public keys from GitHub
  • Writing arbitrary files to the disk

and even more! Feel free to experiment with this, you'll probably find something you'll love in the process.

Let us know what you do with your Pi by mentioning us on the Fediverse, @tailscale on Twitter, or on Bluesky! We'd love to hear about the fun you get up to.
